Portability
Compact enough to move with the work
At 120 × 110 × 60 mm and approximately 500 g, CRISPOT® is easy to transport between testing locations.
Portable Fluorescence Detection
Molecular detection, whenever testing
is needed
CRISPOT® combines controlled incubation and fluorescence detection in one compact instrument for rapid nucleic acid testing in laboratory, on-site and in field settings.
Preset + custom modes
Field-deployable
Compact designWhy CRISPOT®
Molecular testing beyond the laboratory
CRISPOT® enables molecular diagnostic nucleic acid assays to be performed near the point of sample collection, including greenhouses, laboratories, production facilities, agricultural settings, or others.
Throughput
Up to eight samples in a single run
Process eight individual reaction tubes or one compatible 8-tube strip in a flexible testing configuration.
Assay flexibility
Preset workflows or custom conditions
Use established programs or adjust incubation temperature and time for other compatible assays.
Built for practical operation
Integrated fluorescence detection
Supports FAM, FITC, SYTO 9, SYBR Green, and similar fluorophores.
Two power options
Use the supplied AC adapter or a compatible external battery or power bank.
Straightforward operation
Four modes and button-based navigation – no computer or external software required.
Applications
One platform
Multiple applications
CRISPOT® supports compatible assays that require controlled incubation and fluorescence signal detection, including LAMP, RPA, CRISPR-based nucleic acid detection, and other compatible fluorescence-based isothermal workflows.
A flexible platform for molecular assays
Custom mode lets users adjust incubation temperature and time to evaluate and adapt new workflows.
Point-of-need testing
Early identification can support timely crop management and disease-control decisions.
CRISPR + LAMP workflow
The kits combine isothermal amplification with CRISPR-based, target-specific detection.
Available targets
Potato Virus Y, Aggressive Neo-P, Blueberry Scorch Virus, Pseudomonas syringae, Fusarium oxysporum, and more.
Plant pathogen detection
Use CRISPOT® with SignalChem Diagnostics’ One-Pot Plant Pathogen Detection Kits for testing directly at or near the point of sample collection.
Each kit includes target-specific reagents and illustrated instructions.
Animal pathogen detection
One-Pot Animal Pathogen Detection Kits are being developed for veterinary clinics, farms, and other point-of-need settings, with pathogen- and virulence-associated targets for companion and farm animals.
How CRISPOT® works
From sample preparation to fluorescence detection
A clear four-step workflow connects assay-specific sample preparation with controlled incubation and fluorescence detection in CRISPOT®.
01
Prepare the sample
Collect and prepare the sample according to the instructions provided with the selected detection kit or compatible assay.
02
Set up the reaction
Transfer the prepared reaction mixture into compatible tubes. CRISPOT is intended for reaction volumes of 30 µL or greater.
03
Select the program
Choose a preset program or use Custom mode to set the incubation temperature and time required by the assay.
04
Run the test
Start the program. CRISPOT heats the reactions and maintains the selected conditions for the required duration.
Operating modes
Preset for convenience Flexible when required
Four operating modes support sample preparation, established testing workflows, and compatible custom applications.
Navigate directly on the device using simple button controls.
Mode
Temperature
Duration
Best used for
01Heating
60°C
5 min
Preset heating cycle for sample preparation.
02Program 1
63°C
25 min
Preset program for routine fluorescence amplification and detection.
03Program 2
64°C
15 min
Preset program for shorter testing workflows.
CustomUser-programmed
User-programmed
Adjustable temperature and time for other compatible assays.
i
Choose the program specified by the selected detection kit or compatible assay.
Technical specifications
Compact by design Defined by function
120 x 110 x 60 mm500 g
Assay + detection
- Sample capacity
- Up to 8 samples per run
- Reaction volume
- 30 µL or greater
- Light source
- LED light, approximately 490 nm
- Compatible fluorophores
- FAM, FITC, SYTO 9, SYBR Green, and similar fluorophores
- Temperature range
- 25-70°C (77-158°F)
Power + operation
- Operating environment
- Room temperature
- AC adapter input
- 100-240 V AC, 50/60 Hz, 1.2 A
- AC adapter output
- 24 V DC, 2 A
- Power bank requirement
- 15 V or 20 V output
- Rated power
- 30 W with AC adapter; 20 W with power bank
Physical + identification
- Dimensions
- 120 x 110 x 60 mm (4.7 x 4.3 x 2.4 in)
- Weight
- 500 g (1.1 lb)
- Catalog number
- CSP01-V19A
Tube compatibility: Reaction tubes and 8-tube strips from different manufacturers may vary in shape and dimensions. Confirm compatibility before testing. Compatible reaction tubes are available from SignalChem Diagnostics.
